Описание
| Суич, тип |
Fixed Port |
| Общ брой портове |
52 |
| Основни портове, тип |
48x10/100Base-TX |
| Power Over Ethernet (PoE) |
No |
| Uplink портове |
2x10/100/1000Base-T, 2xSFP |
| Свободни (10GB) слотове |
No |
| Управление |
Web user interface: Built-in switch configuration utility for easy browser-based device configuration (HTTP/HTTPS); SNMP: SNMP versions 1, 2c, and 3 with support for traps, and SNMP version 3 user-based security model (USM) |
| Stackable |
No |
| Fans |
Fanless design |
| Захранване |
Internal power adapter; 100-240V 47-63 Hz |
| Routing |
Layer 3 Lite |
| Памет (Flash, RAM) |
Flash Memory: 16 MB; RAM: 128 MB |
| Капацитет за маршрутизиране/превключване, Gbps |
17.6 Gbps |
| Пропускателна способност, Mpps |
13.1 Mpps |
| MAC адреси |
8000 MAC address table size |
| VLAN (брой, стандарти) |
Support for up to 4096 VLANs simultaneously; Port-based and 802.1Q tag-based VLANs; MAC-based VLAN; Management VLAN; Private VLAN Edge (PVE), also known as protected ports, with multiple uplinks |
| QoS |
Priority levels: 4 hardware queues; Scheduling: Strict priority and weighted round-robin (WRR). Queue assignment based on DSCP and class of service (802.1p/CoS); Class of service: Port based; 802.1p VLAN priority based |
| L2 мреживи стандарти |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s |
| L3 мрежови стандарти |
Wirespeed routing of IPv4 packets; Up to 32 static routes and up to 32 IP interfaces; Classless Inter-Domain Routing (CIDR); DHCP relay at Layer 3: Relay of DHCP traffic across IP domains; User Datagram Protocol (UDP) relay |
| IPv6 functionality |
IPv6 host mode; IPv6 over Ethernet; IPv6 neighbor and router discovery (ND); IPv6 stateless address auto-configuration; IPv6 over IPv4 network with Intra-Site Automatic Tunnel Addressing Protocol (ISATAP) support |
| Сигурност |
Secure Shell (SSH) Protocol; Secure Sockets Layer (SSL); IEEE 802.1X (Authenticator role); STP Bridge Protocol Data Unit (BPDU) Guard; Secure Core Technology (SCT); RADIUS/TACACS+; Storm control; ACLs |
| Размери, mm |
440 х 257 x 44.45 mm, 1U Height |
Описанието и спецификацията са създадени с помощта на изкуствен интелект.
