Описание
GENERAL SPECIFICATIONS: |
|
| APPLICATIONS: | 18~20V | 90-WATT MAX. NOTEBOOK PCs |
| COOLING FAN (S): | N/A |
| MAXIMUM OUTPUT POWER: | 90-WATT | 19V @ 4.74A MAXIMUM |
| CAPACITY: | 4.74A |
| VOLTAGE: | 19V |
| OUTPUT CONNECTORS: | 9 I-POINT INTERCHANGEABLE CONNECTORS (BARREL TYPE) |
| CONNECTOR SIZE: | VARIES |
| OPERATING EFFICIENCY: | 87% + |
| OPERATING TEMPERATURE: | 0 ~ 40 °C + |
| OPERATING HUMILITY: | 10 ~ 90% NON-CONDENSING |
| STORAGE TEMPERATURE: | -40 ~ 60 °C + |
| RIPPLE / NOISE: | <150 mVpp |
| SAFETY APPROVAL: | UL/cUL, FCC, TUV, CE, CB |
| MBTF: | 100,000 HOURS @ TYPICAL |
| OTHER TESTS: | 100% HI-POT, 100% BURN-IN @ FULL LOAD |
| UNIT SIZE: | 2.83” (W) x 4.72” (D) x 0.74” (H) |
| UNIT WEIGHT: | 0.47 LB (S) |
| RETAIL PACKAGE: | 4.45” (W) x 1.97” (D) x 10.24” (H) @ 1.2 lbs |
INPUT SPECIFICATIONS: |
|
| Input Voltage: | 100V AC to 240V AC, 47 ~ 63Hz |
| Power Factor Correction (PFC): | AUTO FULL RANGE |
| Input Current: | --- |
| --- | |
| Input Protection: | Patented Input Fuse Protection |
| AC INPUT TYPE: | STANDARD AC CORD (INCLUDED) |
OUTPUT SPECIFICATIONS: |
|
| NUMBER OF OUTPUTS: | 1 |
| Output Voltage: | +18V ~ +20V DC |
| Output Current: | 4.74A @ +19V DC MAXIMUM |
| Output Protection: | Complete OVP, OCP, SCP Protection |
| OVP: | OVER VOLTAGE OUTPUT PROTECTION |
| OCP: | OVER CURRENT OUTPUT PROTECTION |
| SCP: | SHORT CIRCUIT OUTPUT PROTECTION |
За да видите листа със съвместими продукти Кликнете тук!
