Описание
|
WD AV-GP
| Performance Specifications |
 |
|
Rotational Speed |
IntelliPower * |
|
Buffer Size |
32 MB |
|
Acoustics (Sone) |
< 1 |
|
| Transfer Rates |
|
Buffer To Host (Serial ATA) |
3 Gb/s (Max) |
|
| Physical Specifications |
|
|
Formatted Capacity |
500,107 MB |
|
Capacity |
500 GB |
|
Interface |
SATA 3 Gb/s |
|
User Sectors Per Drive |
976,773,168 |
|
| Physical Dimensions |
|
| English |
|
Height |
1.028 Inches |
|
Depth |
5.787 Inches |
|
Width |
4.00 Inches |
|
Weight |
1.39 Pounds |
|
| Metric |
|
Height |
25.4 mm |
|
Depth |
147 mm |
|
Width |
101.6 mm |
|
Weight |
0.63 kg |
|
| Environmental Specifications |
|
| Shock |
|
Operating Shock (Read) |
65G, 2 ms |
|
Non-operating Shock |
300G, 2 ms |
|
| Acoustics |
|
Idle Mode |
24 dBA (average) |
|
Seek Mode 3 |
25 dBA (average) |
|
| Temperature (English) |
|
Operating |
32° F to 140° F |
|
Non-operating |
-40° F to 158° F |
|
| Temperature (Metric) |
|
Operating |
-0° C to 60° C |
|
Non-operating |
-40° C to 70° C |
|
| Humidity |
|
Operating |
5-95% RH non-condensing |
|
Non-operating |
5-95% RH non-condensing |
|
| Vibration |
|
Operating |
|
Linear |
20-300 Hz, 0.75 G (0 to peak) |
|
Random |
0.004 g²/Hz (10 to 300 Hz) |
|
| Electrical Specifications |
|
| Current Requirements |
|
12 VDC |
|
Read/Write |
227 mA |
|
Idle |
161 mA |
|
Standby |
5.4 mA |
|
Sleep |
5.4 mA |
|
|
5 VDC |
|
Read/Write |
550 mA |
|
Idle |
115 mA |
|
Standby |
78.5 mA |
|
Sleep |
78.5 mA |
|
|
Power Dissipation |
|
Read/Write |
5.40 Watts |
|
Idle |
2.50 Watts |
|
Standby |
0.46 Watts |
|
Sleep |
0.46 Watts |
|
| As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576 bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, megabit per second (Mb/s) = one million bits per second, and gigabit per second (Gb/s) = one billion bits per second. |
|
