The SX1000L is provided with greater over-provisioning with higher efficient data compression than is often seen in general SSD controllers. Since in real-world applications most data is compressible, this means sustained performance, endurance and reliability all gain significant improvement. Sequential read speeds reach 550 MB/sec, and sequential write is as high as 500 MB/sec, with IOPS of 73,000 and 45,000 (Maximum 4K random read and write, respectively).
![](https://cdn.jmt.bg/images/descriptions/5345/productImage4365.jpg)
Long-Term Reliability |
The SX1000L employs static wear-leveling technology to maximize device mean time between failures (MTBF) to 1,500,000 hours, providing the long-term dependability required by high density computing and heavy load server operations.
![](https://cdn.jmt.bg/images/descriptions/5345/productImage4351.jpg)
Superior Flash Chips |
The use of multi-level cell (MLC) NAND Flash memory combined with enhanced Flash chip sorting allows for outstanding sustained performance, lower latency, and superior endurance. Enhanced power-loss data protection, easy monitoring of the drive quality through SMART command, and flexible (user-defined) over-provisioning adjustment, all make the SX1000L a superior server solution.
Broad Range of Applications |
The long write endurance and the 5 year warranty of the SX1000L make it extremely suitable for read-centric servers such as web and VOD (Video on demand) servers.
Capacity |
100GB/200GB |
Form Factor |
SATA III 6Gb/sec |
NAND Flash |
Multi-Level Cell (MLC) NAND Flash Memory with enhanced NAND sorting methodology |
Controller |
LSI SandForce SF-2281 |
Dimensions (L x W x H) |
100.25 x 70.1 x 7.0 mm |
Weight |
61 ±1g |
Interface |
SATA 6Gb/sec |
Performance(Max) |
Sequential Read: 550 MB/sec Sequential Write: 500 MB/sec IOPS: 73,000 (Maximum 4K Random Read) IOPS: 45,000 (Maximum 4K Random Write) |
Power Consumption |
0.35W Idle/0.6W Active |
Operating temperature |
0 °C - 70 °C |
Storage temperature |
-40 °C - 85 °C |
Shock resistance |
1500G/0.5ms |
MTBF |
1,500,000 Hours |
Accessories |
2.5” to 3.5” Bracket
7mm to 9.5mm holder
Acronis ATI HD 2013
|
ECC Recovery |
Up to 55 bits correctable per 512-byte sector (BCH)
*varies depending on exact configuration
|
|
|
|
|
