The Premier Pro SP900 M.2 2242 and 2280 SATA 6Gb/s SSDs are built for PC development of the next generation – “faster and smaller”. The SP900 M.2 2242 and 2280 are even smaller than a 2.5” SSD and mSATA, but come with 128/256/512GB in capacity. Both of the two models are suitable for ultrabooks, and the 2280 can also be applied on motherboards. Thanks to the support of Intel® Smart Response Technology, the SP900 M.2 2242 and 2280 provide sequential read/write speeds up to 550/530 MB/s for excellent performance. Additionally, with the support of DVESLP (Device Sleep) technology, the SP900 M.2 2242 and 2280 consumes less power for longer battery life.
Great Compatibility Meets Your Needs |
The SP900 M.2 2242 and 2280 are the smallest SSD form factors in the market, with measurements of only 22 x 42 x 3.5mm (2242) and 22 x 80 x 3.5mm (2280). It is the best solution to upgrade ultrabooks or slim laptops, and the SP900 M.2 2280 also supports motherboards of the next generation.
*For more detailed information on compatible hardware, refer to the website of the relevant notebook and motherboard manufacturers.

Supports Intel® Smart Response Technology |
Intel Smart Response Technology (ISRT) is a caching mechanism, which allows a SATA Solid-State Drive (SSD) to function as cache for a mechanical hard disk drive. Setting up the Premier Pro SP900 M.2 2242 and 2280 with ISRT is convenient and quick.

Lower Power Consumption, Longer Battery Life |
The Premier Pro SP900 M.2 2242 and 2280 support DVESLP (Device Sleep) technology for energy efficiency – it not only reduces the electricity cost, also prolongs the battery life.

Capacity |
128GB |
Form Factor |
M.2 2242 |
NAND Flash |
Synchronous MLC |
Controller |
LSI SF-2281 |
Dimensions (L x W x H) |
22 x 42 x 3.5mm |
Weight |
4g (0.14oz) |
Interface |
SATA 6Gb/sec |
Performance(Max) |
128GB Performance (ATTO) Read : Up to 550MB/s Write : Up to 530MB/s Maximum 4K Random write IOPS up to 85K 256GB Performance (ATTO) Read : Up to 550MB/s Write : Up to 530MB/s Maximum 4K Random write IOPS up to 86K |
Operating temperature |
0~70 °C / -40~85°C |
Storage temperature |
5 ~ 95% RH (0 ~ 55°C) |
Shock resistance |
1500G / 0.5ms |
MTBF |
1,200,000 hours |
|
|
|
|
