General features |
Type |
Inverter |
Power capacity |
1200VA / 840W |
Output Power Factor |
0.70 |
Input |
Input Voltage Range |
170-280 VAC (Narrow Range); 90-280 VAC (Wide Range) |
Frequency Range |
50Hz or 60Hz (self-adaptive) |
Frequency (Synchronized Range) |
50Hz or 60Hz |
Output |
Nominal Output Voltage |
230 VAC |
Pure Sine Wave |
Yes |
Voltage Regulation (Bat. Mod.) |
±5% |
Technical details |
Transfer Time [AC to Battery] |
10ms normal range; 20ms wide range |
Generator support |
Yes |
External Battery Connection |
Yes |
Charger |
10A or 20A (selectable) Recommended Battery Capacity 100 – 200 Ah DC Voltage 12V Floating Charge Voltage 13.5V Low Battery Alarm Voltage 11.5V Shutdown Voltage 10.5V Overcharge Protection 15V |
Protection |
Overload and Short-circuit |
Efficiency |
LINE mode full Load |
88.0% |
Batteries and autonomy time |
