Характеристики
- Dual Channel DDR5 Memory Technology;
- 4 x DDR5 DIMM Slots;
- Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC);
- Max. capacity of system memory: 192GB;
- Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
Integrated AMD RDNA™ 2 graphics (Actual support may vary by CPU);
- 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz;
- 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz
CPU: - 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*;
- 1 x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode*;
Chipset: - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module;
- Supports AMD CrossFire™;
- 15μ Gold Contact in VGA PCIe Slot (PCIE1)
CPU: - 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen5x4 (128 Gb/s) mode*;
Chipset: - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*;
- 1 x M.2 Socket (M2_3, Key M), supports type 2260/2280 PCIe Gen4x2 (32 Gb/s) mode*;
- 4 x SATA3 6.0 Gb/s Connectors
- 2 x Antenna Mounting Points;
- 1 x HDMI Port;
- 1 x DisplayPort 1.4;
- 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s);
- 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s);
- 2 x USB 3.2 Gen1 Ports;
- 4 x USB 2.0 Ports;
- 1 x RJ-45 LAN Port;
- 1 x BIOS Flashback Button;
- HD Audio Jacks: Line in / Front Speaker / Microphone
- 1 x SPI TPM Header;
- 1 x Power LED and Speaker Header;
- 1 x RGB LED Header*;
- 3 x Addressable LED Headers**;
- 1 x CPU Fan Connector (4-pin)***;
- 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****;
- 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****;
- 1 x 24 pin ATX Power Connector;
- 1 x 8 pin 12V Power Connector (Hi-Density Power Connector);
- 1 x Front Panel Audio Connector;
- 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card);
- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports);
- 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports);
- 1 x Front Panel Type C USB 3.2 Gen1 Header
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec);
- Nahimic Audio
- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s;
- Dragon RTL8125BG;
- Supports Dragon 2.5G LAN Software;
- Smart Auto Adjust Bandwidth Control;
- Visual User Friendly UI;
- Visual Network Usage Statistics;
- Optimized Default Setting for Game, Browser, and Streaming Modes;
- User Customized Priority Control
- Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm;
- 2oz Copper PCB
