Описание
Input
Power (kVA) 3
Voltage 160 - 280 VAC
Frequency 50 / 60 Hz. ± 5 %
Power Factor >98%
• Output
Voltage 220VAC / 230VAC
Voltage Regulation ±%2
Power Factor 0,7 lagging
Frequency 50 / 60 Hz (Auto Detection)
Frequency Regulation ±0,5%
Harmonic Distortion < 3 % (For Linaer Loads)
Crest Factor 3:1
Overload Capacity 100% - 120% for 60 seconds, 120% - 150% for 10 seconds
• Battery
DC Voltage 96V
Back up Time Full Load 7 min.
Back up Time Half Load 15 min.
Battery Type Maintenance - Free Sealed lead acid
Recharge Time 8 Hours(To 90% of Full Capacity)
• Efficiency
Whole > 85%
Inverter > 90%
• Transfer
Power failure & recovery 0ms
• Noise Level
1m Distance <52 dBA
• LED Indicators
Line Input, inverter, bypass, fault, overload, battery low, self-test, load/battery level
• Alarm
Line Failure, Battery Low, Transfer to Bypass, Failure Events
• Protection
Short circuit, over temperature, overload, high voltage, battery low
• Communication
Real RS232 Interface Communication Port and UPS Managament Software
• Environment
Operating temperature 0-40 C
Humidity 0-95%
• Physical
Outlets 6pcs IEC and 2pcs Schuko
• Tower Type
Net Weight(kg) 35
Dimensions (mm) WxHxD 190x450x360
