Продуктът не се предлага в момента
Попитайте за дата на доставка:
(+359 2) 965 89 89
Цени за доставка:
Условия и срокове за доставка:
-
Essentials |
||
Status | Launched | |
Launch Date | Q1'16 | |
Expected Discontinuance | See Roadmap | |
Board Form Factor | Compute Stick | |
Socket | Soldered-down BGA | |
# of Internal Drives Supported | 1 | |
Embedded Storage | 32 GB | |
Embedded Options Available | No | |
Lithography | 14 nm | |
DC Input Voltage Supported | 5 VDC | |
Recommended Customer Price | $129.00 | |
Pre-Installed Operating System | Windows 10 Home x86 | |
Datasheet | Link | |
Processor Included | Intel® Atom™ x5-Z8300 Processor (2M Cache, up to 1.84 GHz) | |
Product Brief | Link | |
Additional Information URL | Link | |
Warranty Period | 1 yrs |
-
Memory Specifications |
||
Pre-Installed Memory | 2 GB | |
Memory Types | DDR3L-1600 | |
Max # of Memory Channels | 1 | |
Max Memory Bandwidth | 12.8 GB/s | |
Physical Address Extensions | 32-bit |
-
Graphics Specifications |
||
Integrated Graphics ‡ | Yes | |
Graphics Output | HDMI 1.4b | |
# of Displays Supported ‡ | 1 |
-
Expansion Options |
||
Removable Memory Card Slot | MicroSDXC with UHS-I support |
-
I/O Specifications |
||
USB Revision | 2.0, 3.0 | |
# of USB Ports | 2 | |
USB 3.0 Configuration (External + Internal) | 1 | |
Integrated Wifi | Intel® Wireless-AC 7265 + BT 4.2 | |
Integrated Bluetooth | Yes |
-
Package Specifications |
||
Low Halogen Options Available | See MDDS |
-
Advanced Technologies |
||
Intel® Virtualization Technology (VT-x) ‡ | Yes |
-
Intel® Data Protection Technology |
||
Intel® AES New Instructions | Yes |
System | |
System Type: | Personal Computer Barebone |
System Form Factor: | Stick |
Built-in Devices: | Card Reader |
Included Accessories: | Power Adapter |
Processor | |
CPU: | Intel Atom x5-Z8300 Processor |
Internal Clock Rate: | 1.44 GHz (up to 1.84 GHz) |
CPU Core Quantity: | 4 |
CPU Socket Standard: | Socket 592 |
CPU Installed Quantity: | 1 |
CPU Maximum Quantity Supports: | 1 |
Installed L2 Cache Memory Storage Capacity: | 2 MB |
Features: | Supports 14 nm Processors |
Quantity of Mainboards Supported: | 1 |
Memory | |
Memory Type: | DDR3 SDRAM |
Memory Speed: | 1600MHz(PC3-12800) |
Installed System Memory Storage Capacity: | 2 GB |
Storage | |
Storage: | Flash Memory 1x32 GB |
Video Output | |
Video Controller Form Factor: | Integrated |
Video Chipset: | Intel HD Graphics |
Video Memory Type: | Shared Video Memory |
Audio Output | |
Audio Controller Form Factor: | integrated |
Audio Output Mode: | 8 Channels |
Audio Data Width: | 24-bit |
Compliant Audio Standards: | High Definition Audio |
Networking Specifications | |
Wi-Fi: | IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac |
Bluetooth: | Bluetooth 4.0 |
Interface Provided | |
USB2.0: | 1 (4-pin USB (type A)) ( x 1) |
USB3.0: | 1 (USB 3.0 (type A)) ( x 1) |
HDMI: | 1 (HDMI (Type A)) ( x 1) |
Software | |
Name of OS: | Microsoft Windows 10 |
Power | |
Power Device Type: | Power Adapter |
Power Device Location: | External |
Input Voltage: | AC 100-240 V |
Input Frequency: | 50/60 Hz |
Miscellaneous | |
Package Type: | Retail |
External Colour: | Black |
Included Accessories: | Power Adapter |
Cable Included: | HDMI Cable |
Environment | |
Maximum Operating Ambient Temperature: | 35 °C |
Minimum Operating Ambient Temperature: | 0 °C |
Dimensions & Weight Device | |
Height (mm): | 38 mm |
Depth (mm): | 12 mm |
Width (mm): | 113 mm |
Nominal Weight: | 0.06 kg |
