Specification |
Display Support |
3 x Maximum Display Monitor(s) support with 1 DisplayPort connected 3 x Maximum Display Monitor(s) support |
Output |
1 x HDMI (with 3D) 1 x DisplayPort 1.2 1 x Dual-Link DVI-I |
GPU |
950 MHz Core Clock 28 nm Chip 640 x Stream Processors |
Video Memory |
2048 MB Size 128 -bit GDDR5 4800 MHz Effective |
Dimension |
155(L)x104(W)x35(H) mm Size. 2 x slot |
Software |
Driver CD SAPPHIRE TriXX Utility |
Accessory |
DVI to VGA Adapter 6 PIN to 4 PIN Power Cable |
Overview |
|
HDMI (with 3D)
Support for Deep Color, 7.1 High Bitrate Audio, and 3D Stereoscopic, ensuring the highest quality Blu-ray and video experience possible from your PC.
|
|
|
DisplayPort 1.2
Doubling the effective bandwidth of previous DisplayPort implementations, DisplayPort 1.2 now includes support for Multi-Stream, allowing you to drive up to four separate monitors from a single DisplayPort 1.2 connector (requires DP1.2 monitors or Multi-Stream compatible hub), Stereoscopic 3D monitor support and adds support for high quality, lossless, 7.1 channel audio formats.
|
|
|
Dual-Link DVI-I
Equipped with the most popular Dual Link DVI (Digital Visual Interface), this card is able to display ultra high resolutions of up to 2560 x 1600 at 60Hz.
|
|
|
AMD Eyefinity
AMD Eyefinity technology maximises your field of view across up to three displays, fully engaging your peripheral vision. For gamers this puts you right IN the game and for other applications it helps to increase productivity by maximising your visual workspace so that you can see more windows simultaneously. AMD Eyefinity technology is also ideal for multimedia applications as it allows you to keep several ‘palettes’ or ‘panels’ open over a larger workspace whist you edit your images or videos.*
*To support 3 displays, one of the monitors has to support DisplayPort *With Sapphire Flex Technology, this requirement will be no necessary **When running Microsoft Windows XP, Eyefinity technlogy supports a maximum of 2 displays.
|
|
|
Advanced GDDR5 Memory Technology
GDDR5 memory provides twice the bandwidth per pin of GDDR3 memory, delivering more speed and higher bandwidth.
|
|
|
AMD HD3D Technology
Enjoy the most immersive experience possible with full support for High Definition Stereoscopic 3D, a technique that presents 2D images (movies, games, photos) in a format that creates the illusion of three-dimensional depth when using compatible 3D displays / glasses / software.
|
|
|
28 nm GCN (Graphic Core Next) Architecture
The new 28nm GCN Architecture’s more efficient process technology puts more transistors in less space, enabling a dramatic increase in processing power
|
|
|
PCI Express 3.0
PCI-Express 3.0 delivers double the bandwidth per lane of PCIe Gen 2 for faster GPU (GPU communication-up to 16GB/sec in each direction), maximizing the performance from your GPU when paired with the latest platforms.
|
|
|
Best Microsoft DirectX11 Support
The tessellation performance on AMD Radeon HD7000 is up to 2X faster than the previous generation, and DirectCompute performance is also faster to accelerate advanced post-processing, filtering, and anti-aliasing techniques. Direct X11 games has never looked this good.
|
|
|
DirectX® 12
The tessellation performance on AMD Radeon R7/ R9 series is up to 2X faster than the previous generation, and DirectCompute performance is also faster to accelerate advanced post-processing, filtering, and anti-aliasing techniques. Direct X12 games has never looked this good. * Based on preliminary DirectX 12 specifications as of July, 2014, AMD’s GCN-based products are expected to support DirectX 12 upon its release. The DirectX 12 specification and support for it are subject to change without notice.
|
|
|
OpenGL 4.3
OpenGL 4.3 improves the GPU efficiency by improving the shader process operation and capturing GPU tessellated geometry. The process of modifying an arbitrary subset of compress texture is also simplified. The memory management in handling shaders is more efficient as well.
|
|
|
Mantle
Properly enabled games will reach new heights of performance by speaking the language of Graphics Core Next architecture.
|
|
|
AMD App Acceleration
AMD App Acceleration is a set of technologies designed to improve video quality and enhance application performance. Full enablement of some features requires support for OpenCL, DirectCompute or DirectX Video Acceleration (DXVA).
|
|
|
AMD HD Media Accelerator
AMD HD Media Accelerator has been designed to help optimize and dramatically improve video playback on your computer by taking advantage of hardware video acceleration from your AMD Radeon GPU. With full 3D stereoscopic decode you can enjoy it all in 3D. AMD HD Media Accelerator speeds up the decode of one 1080p and one 1080i HD video streams simultaneously by hardware, and the new hardware encodes/transcoder processes your media content faster than ever!
|
|
|
Cutting-edge Quad HD display support (4K Support)
The display resolution is quadrupled to the resolution of 4KX2K( 4096X2160 ) from the outputs of DisplayPort 1.2 and HDMI.
|
|
|
Cutting-edge Quad HD display support (4K Support) [for Windows OS only]
The display resolution on AMD Radeon HD7000 series is quadrupled to the resolution of 4KX2K( 4096X2160 ) from the outputs of DisplayPort 1.2 and HDMI.
|
|
|
Enhanced Unified Video Decoder(UVD) [for Windows OS only]
Watch the hottest Blu-ray movies or other HD content at full 1080p (and beyond !) display resolution. Enjoy a feature rich video experience with enhanced Unified Video Decoder (UVD), offloading the bulk of the video decoding tasks from the CPU to the GPU allowing for a cooler, quieter and more balanced system.
|
|
|
Windows® 8/8.1 support
WHQL (Windows Hardware Quality Labs) Certified drivers and logos are available for SAPPHIRE cards ensuring compatibility and reliability with Microsoft Windows 8/8.1.
|
|
|
|
