GPU
- Radeon™ RX 5700 Graphics
- 2nd Gen 7nm GPU
- RDNA Architecture
Engine Clock
- Boost Clock: Up to 1725 MHz
- Game Clock: 1625 MHz
- Base Clock: 1465 MHz
Stream Processors
2304
Memory Size/Bus
8GB/256 bit GDDR6
Memory Clock
14 Gbps Effective
Displays
Maximum 4 Displays
Resolution
HDMI™: 4096×2160@60Hz
DisplayPort1.4: 5120×2880@60Hz
Interface
PCI-Express 4.0
Output
BIOS Support
API
- OpenGL® 4.5
- OpenCL 2.0
- DirectX® 12
- Shader Model 5.0
Game Index
Extreme 1440P
- RDNA Architecture
- 2nd Gen 7nm GPU
- GDDR6 Memory
- Power Efficiency
- PCI Express 4.0 Support
- Video Streaming up to 8K
- Display Port 1.4 (HBR3) / DSC
- Radeon™ Software
- Radeon™ Boost
- Radeon™ Image Sharpening
- Radeon™ Anti-Lag
- AMD FidelityFx
- Async Compute
- Radeon™ Rays Audio + True Audio Next
- Radeon™ FreeSync™ 2 HDR
- Radeon™ VR Ready Premium
Cooling
Blower
Form Factor
2 slot, ATX
Dimension: 268(L)X 111(W)X 36 (H)mm
Power Consumption
OS
Windows® 10, Windows® 7 64bit operating system required
System Requirement
- Minimum 600 Watt Power Supply (Recommended).
- 1 x 8-pin Power Connector.
- 1 x 6-pin Power Connector.
- PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
- Minimum 8GB of system memory. 16GB recommended.
