Synology DS220j NAS 2-bay Server for Home and Small office

Продуктов код: 47089
NAS устройство Synology
NAS устройство Synology DS220J NAS устройство Synology DS220J NAS устройство Synology DS220J NAS устройство Synology DS220J
NAS устройство Synology
Все още няма оценка за продукта.
Напиши ревю | Задай въпрос
Производител:
Synology
Модел:
DS220J
Партиден номер:
-
Гаранция:
24 месеца

Продуктът не се предлага в момента

Попитайте за дата на доставка:
(+359 2) 965 89 89

  • Описание
  • Видео (1)
  • Ревюта
  • Въпроси и отговори

Synology DS220J

Технически данни

CPU
 CPU Model Realtek RTD1296

 CPU Architecture 64-bit

 CPU Frequency Quad Core 1.4 GHz

 Hardware Encryption Engine  V
Memory
 System Memory 512 MB DDR4

 Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
 Drive Bays 2

 Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA HDD (with optional 2.5" Disk Holder)
  • 2.5" SATA SSD (with optional 2.5" Disk Holder)

 Maximum Internal Raw Capacity 32 TB (16 TB drive x 2) (Capacity may vary by RAID types)

 Maximum Single Volume Size* 108 TB

 Hot Swappable Drive -

 Notes
  • "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
 RJ-45 1GbE LAN Port 1

 USB 3.0 Port 2
File System
 Internal Drives
  • EXT4

 External Drives
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*

 Notes exFAT Access is purchased separately in Package Center.
Appearance
 Size (Height x Width x Depth) 165 mm x 100 mm x 225.5 mm

 Weight 0.88 kg
Others
 System Fan 92 mm x 92 mm x 1 pcs

 Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
  • Low-power Mode

 Brightness Adjustable Front LED Indicators  V

 Power Recovery  V

 Noise Level* 18.2 dB(A)

 Scheduled Power On / Off  V

 Wake on LAN / WAN  V

 Power Supply Unit / Adapter 60 W

 AC Input Power Voltage 100 V to 240 V AC

 Power Frequency 50/60 Hz, Single Phase

 Power Consumption* 12.46 W (Access)
5.06 W (HDD Hibernation)

 British Thermal Unit 45.52 BTU/hr (Access)
17.27 BTU/hr (HDD Hibernation)

 Notes
  • Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
 Operating Temperature 0°C to 40°C (32°F to 104°F)

 Storage Temperature -20°C to 60°C (-5°F to 140°F)

 Relative Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • EAC
  • BSMI
  • VCCI
  • CCC
  • RCM
  • KC
Warranty
 2 Years

 Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
 RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 1
  • Quick Installation Guide X 1
Optional Accessories
  • Surveillance Device License Pack
  • VS360HD
  • VS960HD
  • Disk Holder: Type C

DSM Specifications

Storage Management
 Maximum Internal Volume Number 64

 Maximum iSCSI Target Number 10

 Maximum iSCSI LUN 10

 Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1

 RAID Migration Basic to RAID 1

 Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1

 Volume Expansion by Adding a HDD Synology Hybrid RAID
File Services
 File Protocol CIFS/AFP/NFS/FTP/WebDAV

 Maximum Concurrent CIFS/AFP/FTP Connections 100

 Windows Access Control List (ACL) Integration  V

 NFS Kerberos Authentication  V
Account & Shared Folder
 Maximum Local User Accounts 1,024

 Maximum Local Groups 256

 Maximum Shared Folder 256

 Maximum Shared Folder Sync Tasks 2
Log Center
 Syslog Events per Second 100
General Specifications
 Networking Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

 Supported Browsers
  • Chrome
  • Firefox
  • Edge
  • Internet Explorer 10 onwards
  • Safari 10 onwards
  • Safari (iOS 10 onwards)
  • Chrome (Android 6.0 onwards)

 Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文
Add-on Packages view the complete package list
Synology Chat
 Maximum Users 10

 Notes
  • The number of concurrent HTTP connections for Synology Chat was configured to the maximum.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
Download Station
 Maximum Concurrent Download Tasks 50
exFAT Access (Optional)
  V
Media Server
 DLNA Compliance  V
Moments
 Facial Recognition  V
Surveillance Station
 Maximum IP cam (Licenses required) 12 (including 2 Free License) (See All Supported IP Cameras)

 Total FPS (H.264) 360 FPS @ 720p (1280x720)
110 FPS @ 1080p (1920x1080)
70 FPS @ 3M (2048x1536)
40 FPS @ 5M (2591x1944)
30 FPS @ 4K (3840x2160)

 Total FPS (H.265) 360 FPS @ 720p (1280x720)
240 FPS @ 1080p (1920x1080)
110 FPS @ 3M (2048x1536)
70 FPS @ 5M (2591x1944)
40 FPS @ 4K (3840x2160)

 Total FPS (MJPEG) 80 FPS @ 720p (1280x720)
50 FPS @ 1080p (1920x1080)
40 FPS @ 3M (2048x1536)
20 FPS @ 5M (2591x1944)

 Notes
  • Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
  • The maximum channel number also includes devices installed on Virtual DSM.
  • Total FPS may be affected by other services running at the same time (e.g., archive tasks performed by Archive Vault).
Synology Drive
 Recommended Number of Hosted Files 100,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)

 Recommended Number of Concurrent Sync Clients 200 (the number of connections that can be maintained when the recommended number of hosted files was reached)

 Notes
  • Exceeding the limits above may result in longer response time in file operations.
  • EXT4 file system and non-encrypted shared folders were used during the aforementioned testing.
Synology Office
 Maximum Users 200

 Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Video Station
 Video Transcoding Group 2 (See more)
VPN Server
 Maximum Connections 10
