24-bay Synology NAS server for Small and Medium Business(12 bays on base, expandable to 24 with 1x DX1215), DS2419+ 60 месеца гаранция

Продуктов код: 55803
NAS устройство Synology
NAS устройство Synology DS2419+_EW NAS устройство Synology DS2419+_EW NAS устройство Synology DS2419+_EW NAS устройство Synology DS2419+_EW NAS устройство Synology DS2419+_EW
NAS устройство Synology
Все още няма оценка за продукта.
Напиши ревю | Задай въпрос
Производител:
Synology
Модел:
-
Партиден номер:
DS2419+_EW
Гаранция:
60 месеца

Продуктът не се предлага в момента

Попитайте за дата на доставка:
(+359 2) 965 89 89

  • Описание
  • Ревюта
  • Въпроси и отговори

Synology DS2419+_EW

  • Параметри24-bay Synology NAS server for Small and Medium Business(12 bays on base, expandable to 24 with 1x DX1215), DS2419+
  • Други:  Quad Core 2.1GHz CPU, 4GB DDR4 RAM, 2x USB3.0, 4x Gbit LAN, 1x PCIe x8(x4), max. internal HDD 12x 14TB (not incl.),RAID 0,1,5,6,10, hotswap HDD, eSATA x1

Технически данни

Hardware Specifications
CPU
CPU Model Intel Atom C3538
CPU Architecture 64-bit
CPU Frequency Quad Core 2.1 GHz
Hardware Encryption Engine (AES-NI) V
Memory
System Memory 4 GB DDR4
Memory Module Pre-installed 4 GB (4 GB x 1)
Total Memory Slots 2
Memory Expandable up to 32 GB (16 GB x 2)
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 12
Maximum Drive Bays with Expansion Unit 24
Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA HDD
  • 2.5" SATA SSD
Maximum Internal Raw Capacity 168 TB (14 TB drive x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units 336 TB (168 TB + 14 TB drive x 12) (Capacity may vary by RAID types)
Maximum Single Volume Size 108 TB
Hot Swappable Drive V
Notes
  • "Compatible drive type" indicates the drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
  • Expansion of the internal volume is only supported if the combined single volume size does not exceed the maximum limit of 108TB.
External Ports
RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)
USB 3.0 Port 2
Expansion Port 1
PCIe
PCIe Expansion 1 x Gen3 x8 slot (black, x4 link)
Add-in-card support
  • M2D18 - Dual M.2 SATA/NVMe SSD adapter card for SSD cache
  • PCIe Network Interface Card (Learn more)
File System
Internal Drives
  • Btrfs
  • EXT4
External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 270 mm x 300 mm x 340 mm
Weight 9.5 kg
Others
System Fan 120 mm x 120 mm x 2 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Easy Replacement System Fan V
Power Recovery V
Noise Level* 22.3 dB(A)
Scheduled Power On/Off V
Wake on LAN/WAN V
Power Supply Unit / Adapter 500W
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 101.6 W (Access)
43.96 W (System Hibernation)
British Thermal Unit 346.9 BTU/hr (Access)
150.09 BTU/hr (System Hibernation)
Environment Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • EAC
  • VCCI
  • CCC
  • RCM
Warranty 3 Year Hardware Warranty
Notes
  • Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Support for Wake on WAN needs switch and routers which recognize Magic Packet.
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
DSM Specifications ( See more )
Storage Management
Maximum Internal Volume Number 512
Maximum iSCSI Target Number 128
Maximum iSCSI LUN 256
iSCSI LUN Clone/Snapshot, Windows ODX V
SSD Read/Write Cache (White Paper) V
SSD TRIM V
Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5
  • RAID 1 to RAID 5
  • RAID 5 to RAID 6
Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
Volume Expansion by Adding a HDD
  • Synology Hybrid RAID
  • JBOD
  • RAID 5
  • RAID 6
Global Hot Spare Supported RAID Type
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
File Services
File Protocol CIFS/AFP/NFS/FTP/WebDAV
Maximum Concurrent CIFS/AFP/FTP Connections 1,000
Maximum Concurrent CIFS/AFP/FTP Connections (with RAM expansion) 2,000
Windows Access Control List (ACL) Integration V
NFS Kerberos Authentication V
Account & Shared Folder
Maximum Local User Accounts 2,048
Maximum Local Groups 256
Maximum Shared Folder 512
Maximum Shared Folder Sync Tasks 16
High Availability Manager
Log Center
Syslog Events per Second 800
Virtualization
VMware vSphere 6 with VAAI V
Windows Server 2016 V
Citrix Ready V
OpenStack V
Add-on Packages (learn more about the complete add-on package list)
Antivirus by McAfee (Trial) V
Central Management System V
Chat V
Maximum Users 1,500
Notes
  • The number of concurrent HTTP connections for Chat was configured to the maximum.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
Cloud Station Server V
Maximum Number of Concurrently Connected Devices 1,000
Maximum Number of Concurrently Connected Devices (with RAM expansion) 2,000
Maximum Number of Hosted Files (btrfs) 1,000,000
Maximum Number of Hosted Files (ext4) 1,000,000
Notes
  • The maximum number of concurrently connected devices refers to the maximum number of devices that can remain connected at the same time.
  • The maximum number of hosted files refers to the maximum number of files that can be indexed and hosted by the Cloud Station Server service. RAM expansion was not used during testing.
  • Non-encrypted shared folders were used during the aforementioned testing.
Document Viewer
Download Station
Maximum Concurrent Download Tasks 80
exFAT Access (optional) V
MailPlus / MailPlus Server V
Free Email Accounts (Licenses required for additional accounts)
Maximum number of concurrent users Up to 150
Maximum Server Performance 1,484,000 emails per day, approx. 45 GB
Notes
  • The CPU and RAM usage were both under 80% when testing the maximum number of concurrent users.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Read-write SSD cache was enabled in 5-bay (and above) NAS models with 2 SSDs units installed.
  • The performance of the mail system will slightly decrease in high-availability mode due to data synchronization between the two servers.
  • Functions that were enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist, content scan, full-text search (English only).
Media Server V
DLNA Compliance V
Moments V
Facial recognition V
Subject recognition V
Auto Color & Rotate V
Moments Select V
Snapshot Replication V
Maximum Snapshots per Shared Folder 1024
Maximum of system snapshots 65536
Surveillance Station V
Maximum IP cam (Licenses required) 40 (including 5 Free License) (See All Supported IP Cameras)
Total FPS (H.264)* 1200 FPS @ 720p (1280x720)
960 FPS @ 1080p (1920×1080)
520 FPS @ 3M (2048x1536)
320 FPS @ 5M (2591x1944)
240 FPS @ 4K (3840x2160)
Total FPS (H.265)* 1200 FPS @ 720p (1280x720)
1200 FPS @ 1080p (1920×1080)
880 FPS @ 3M (2048x1536)
520 FPS @ 5M (2591x1944)
400 FPS @ 4K (3840x2160)
Total FPS (MJPEG)* 560 FPS @ 720p (1280x720)
270 FPS @ 1080p (1920×1080)
190 FPS @ 3M (2048x1536)
110 FPS @ 5M (2591x1944)
Notes Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
Synology Drive V
Recommended Number of Hosted Files 1,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
Recommended Number of Concurrent Connections for PC Clients 550 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Notes
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Exceeding the limits above may result in longer response time in file operations.
  • Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.
Synology Office V
Maximum Users 1,800
Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Video Station V
Video Transcoding Group 1 - Type 1 (See more)
Maximum Transcoding Channel Number 1 channel, 30 FPS @ 1080p(1920×1080), H.264 (AVC)/MPEG-4 Part 2 (XVID, DIVX5)/MPEG-2/VC-1
Virtual Machine Manager
Recommended Virtual Machine Instances 4 (Learn more)
Recommended Virtual DSM Number(Licenses required) 4 (including 1 Free License)
Notes Virtual Machine Manager is not supported on hosts running Synology High Availability.
VPN Server
Maximum Connections 30
Environment & Packaging
Environment RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
  • Surveillance Device License Pack
  • D4NS2133-4G DDR4 non-ECC SO-DIMM*
  • RAMEC2133DDR4SO-16G DDR4 ECC SO-DIMM
  • Expansion Unit: DX1215 X 1
  • VS360HD
  • VS960HD
  • Synology Ethernet Adapter E10G18-T1
  • Synology Ethernet Adapter E10G18-T2
  • Synology Ethernet Adapter E10G17-F2
  • Synology M2D18 M.2 SSD adapter card
Notes
  • For more information on memory upgrade limitations, visit here.
  • If multiple memory modules of different frequency are installed in the same system, all memory modules will be operated at the lowest frequency available.
