Synology DS420J 4-bay NAS Server Home and Small office

Продуктов код: 47090
NAS устройство Synology
NAS устройство Synology DS420J NAS устройство Synology DS420J NAS устройство Synology DS420J
NAS устройство Synology
Все още няма оценка за продукта.
Напиши ревю | Задай въпрос
Производител:
Synology
Модел:
DS420J
Партиден номер:
DS420J
Гаранция:
24 месеца

Продуктът не се предлага в момента

Попитайте за дата на доставка:
(+359 2) 965 89 89

  • Описание
  • Ревюта
  • Въпроси и отговори

Synology DS420J

Технически данни

CPU CPU Model Realtek RTD1296
  CPU Architecture 64-bit
  CPU Frequency Quad Core 1.4 GHz
  Hardware Encryption Engine
Memory System Memory 1 GB DDR4
  Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage Drive Bays 4
  Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA HDD
  • 2.5" SATA SSD
  Maximum Internal Raw Capacity 64 TB (16 TB drive x 4) (Capacity may vary by RAID types)
  Maximum Single Volume Size* 108 TB
  Hot Swappable Drive -
  Notes
  • "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports RJ-45 1GbE LAN Port 1
  USB 3.0 Port 2
File System Internal Drives
  • EXT4
  External Drives
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
  Notes exFAT Access is purchased separately in Package Center.
Appearance Size (Height x Width x Depth) 184 mm x 168 mm x 230 mm
  Weight 2.21 kg
Others System Fan 80 mm x 80 mm x 2 pcs
  Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
  • Low-power Mode
  Brightness Adjustable Front LED Indicators  V
  Power Recovery  V
  Noise Level* 20.6 dB(A)
  Scheduled Power On / Off  V
  Wake on LAN / WAN  V
  Power Supply Unit / Adapter 90 W
  AC Input Power Voltage 100 V to 240 V AC
  Power Frequency 50/60 Hz, Single Phase
  Power Consumption* 21.71 W (Access)
7.88 W (HDD Hibernation)
  British Thermal Unit 74.08 BTU/hr (Access)
26.89 BTU/hr (HDD Hibernation)
  Notes
  • Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature Operating Temperature 0°C to 40°C (32°F to 104°F)
  Storage Temperature -20°C to 60°C (-5°F to 140°F)
  Relative Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • EAC
  • BSMI
  • VCCI
  • CCC
  • RCM
Warranty 2 Years
  Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 1
  • Quick Installation Guide X 1
Optional Accessories
  • Surveillance Device License Pack
  • VS360HD
  • VS960HD



DSM Specifications

Storage Management Maximum Internal Volume Number 64
  Maximum iSCSI Target Number 10
  Maximum iSCSI LUN 10
  SSD TRIM  V
  Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
  RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5
  • RAID 1 to RAID 5
  • RAID 5 to RAID 6
  Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
  Volume Expansion by Adding a HDD
  • Synology Hybrid RAID
  • JBOD
  • RAID 5
  Global Hot Spare Supported RAID Type
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
File Services File Protocol CIFS/AFP/NFS/FTP/WebDAV
  Maximum Concurrent CIFS/AFP/FTP Connections 100
  Windows Access Control List (ACL) Integration  V
  NFS Kerberos Authentication  V
Account & Shared Folder Maximum Local User Accounts 1,024
  Maximum Local Groups 256
  Maximum Shared Folder 256
  Maximum Shared Folder Sync Tasks 4
Log Center Syslog Events per Second 100
General Specifications Networking Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
  Supported Browsers
  • Chrome
  • Firefox
  • Edge
  • Internet Explorer 10 onwards
  • Safari 10 onwards
  • Safari (iOS 10 onwards)
  • Chrome (Android 6.0 onwards)
  Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文
Add-on Packages view the complete package list
Synology Chat Maximum Users 10
  Notes
  • The number of concurrent HTTP connections for Synology Chat was configured to the maximum.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
Download Station Maximum Concurrent Download Tasks 80
exFAT Access (Optional)  V
Media Server DLNA Compliance  V
Moments Facial Recognition  V
  Subject Recognition  V
Surveillance Station Maximum IP cam (Licenses required) 16 (including 2 Free License) (See All Supported IP Cameras)
  Total FPS (H.264)* 480 FPS @ 720p (1280x720)
288 FPS @ 1080p (1920x1080)
150 FPS @ 3M (2048x1536)
100 FPS @ 5M (2591x1944)
70 FPS @ 4K (3840x2160)
  Total FPS (H.265)* 480 FPS @ 720p (1280x720)
384 FPS @ 1080p (1920x1080)
256 FPS @ 3M (2048x1536)
160 FPS @ 5M (2591x1944)
100 FPS @ 4K (3840x2160)
  Total FPS (MJPEG)* 240 FPS @ 720p (1280x720)
150 FPS @ 1080p (1920x1080)
100 FPS @ 3M (2048x1536)
60 FPS @ 5M (2591x1944)
  Notes Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
Synology Drive Recommended Number of Hosted Files 100,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
  Recommended Number of Concurrent Sync Clients 200 (the number of connections that can be maintained when the recommended number of hosted files was reached)
  Notes
  • Exceeding the limits above may result in longer response time in file operations.
  • EXT4 file system and non-encrypted shared folders were used during the aforementioned testing.
Synology Office Maximum Users 200
  Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Video Station Video Transcoding Group 2 (See more)
VPN Server Maximum Connections 10
