24-bay Synology NAS Server for Small and Medium Business( 12 bays on base, expandable to 24 with RX1217/RX1217RP) , redundant PSU, 2U Rackmount RS2421RP+

Продуктов код: 55784
NAS устройство Synology
NAS устройство Synology RS2421RP+ NAS устройство Synology RS2421RP+ NAS устройство Synology RS2421RP+ NAS устройство Synology RS2421RP+ NAS устройство Synology RS2421RP+ NAS устройство Synology RS2421RP+
NAS устройство Synology
Все още няма оценка за продукта.
Напиши ревю | Задай въпрос
Производител:
Synology
Модел:
-
Партиден номер:
RS2421RP+
Гаранция:
36 месеца

Продуктът не се предлага в момента

Попитайте за дата на доставка:
(+359 2) 965 89 89

  • Описание
  • Ревюта
  • Въпроси и отговори

Synology RS2421RP+

  • Параметри: 24-bay Synology NAS Server for Small and Medium Business( 12 bays on base, expandable to 24 with RX1217/RX1217RP) , redundant PSU, 2U Rackmount RS2421RP+
  • Други:  AMD Ryzen V1500B 4 core 2.2 GHz, 4GB DDR4 RAM, 2x USB3.0, 1x eSATA, max. internal 12x 3.5", 2.5" HDD/SSD, hotswap HDD, EXT4 and Btrfs

Технически данни

CPU

 CPU Model AMD Ryzen V1500B
  CPU Quantity 1
  CPU Architecture 64-bit
  CPU Frequency 4-core 2.2 GHz
  Hardware Encryption Engine (AES-NI)

Memory

 System Memory 4 GB DDR4 ECC UDIMM
  Memory Module Pre-installed 4 GB (4 GB x 1)
  Total Memory Slots 2
  Maximum Memory Capacity 32 GB (16 GB x 2)
  Notes
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage

 Drive Bays 12
  Maximum Drive Bays with Expansion Unit 24 (RX1217/RX1217RP x 1)
  Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA HDD
  • 2.5" SATA SSD
  Maximum Single Volume Size* 108 TB
  Hot Swappable Drive
  Notes
  • It is strongly recommended that you only install drives listed on your device's compatibility list. Storage pool and volume creation processes may fail when using unverified drives. Synology is unable to provide technical support for devices using unsupported components.
  • "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • Each internal volume (may consist of multiple drives) is expandable up to 108TB.

External Ports

 RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)
  USB 3.2 Gen 1 Port* 2
  Expansion Port 1
  Notes The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

PCIe

 PCIe Expansion 1 x Gen3 x8 slot (x4 link)

File System

 Internal Drives
  • Btrfs
  • EXT4
  External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
  Notes exFAT Access is purchased separately in Package Center.

Appearance

 Form Factor (RU) 2U
  Size (Height x Width x Depth) RS2421+ : 88 mm x 482 mm x 552 mmRS2421RP+ : 88 mm x 482 mm x 578 mm
  Weight RS2421+ : 11.5 kgRS2421RP+ : 11.9 kg
  Rack Installation Support* 4-post 19" rack (Synology Rail Kit - RKS1317)
  Notes The rail kit is sold separately

Others

 System Fan 60 mm x 60 mm x 3 pcs
  Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
  Easy Replacement System Fan
  Power Recovery
  Noise Level* RS2421+ : 50.1 dB(A)RS2421RP+ : 54 dB(A)
  Scheduled Power On / Off
  Wake on LAN / WAN
  Power Supply Unit / Adapter RS2421+ : 500 WRS2421RP+ : 350 W
  Redundant Power Supply RS2421+ : -RS2421RP+ :
  AC Input Power Voltage 100 V to 240 V AC
  Power Frequency 50/60 Hz, Single Phase
  Power Consumption* RS2421+ : 79.56 W (Access) 34.89 W (HDD Hibernation)
RS2421RP+ : 91.76 W (Access) 48.21 W (HDD Hibernation)
  British Thermal Unit RS2421+ : 271.65 BTU/hr (Access) 119.13 BTU/hr (HDD Hibernation)
RS2421RP+ : 313.31 BTU/hr (Access) 164.61 BTU/hr (HDD Hibernation)
  Notes
  • Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

 Operating Temperature 0°C to 35°C (32°F to 95°F)
  Storage Temperature -20°C to 60°C (-5°F to 140°F)
  Relative Humidity 5% to 95% RH

Certification
  • FCC
  • CE
  • BSMI
  • EAC
  • CCC
  • KC
  • UL
  • VCCI
  • RCM

Warranty

 3-year hardware warranty, extendable to 5-year coverage - EW202
  Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

 RoHS Compliant

Packaging Content

 RS2421+ :
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 1
  • Quick Installation Guide X 1
RS2421RP+ :
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 2
  • Quick Installation Guide X 1

Optional Accessories
  Notes All memory modules will operate at the maximum frequency specified by the CPU manufacturer.

DSM Specifications

Storage Management

 Maximum Internal Volume Number 64
  SSD Read / Write Cache (White Paper) V
  SSD TRIM V
  Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
  RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5
  • RAID 1 to RAID 5
  • RAID 5 to RAID 6
  Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
  Volume Expansion by Adding a HDD
  • Synology Hybrid RAID
  • JBOD
  • RAID 5
  • RAID 6
  Global Hot Spare Supported RAID Type
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10

File Services

 File Protocol SMB/AFP/NFS/FTP/WebDAV
  Maximum Concurrent SMB/AFP/FTP Connections 1,000
  Maximum Concurrent SMB/AFP/FTP Connections (with RAM expansion) 2,000
  Windows Access Control List (ACL) Integration V
  NFS Kerberos Authentication V
  Notes
  • Regarding data concerning tests with RAM expansion, all memory slots are installed with the maximum capacity of supported RAM.
  • The testing standard was based on the maximum number of concurrent connections supported by this model. During the testing, 25% of the connections were used to transfer files concurrently. The transfer process guaranteed that the connections were not interrupted; the minimum transfer speed was not guaranteed.

Account & Shared Folder

 Maximum Local User Accounts 2,048
  Maximum Local Groups 256
  Maximum Shared Folder 512
  Maximum Shared Folder Sync Tasks 16

High Availability

 Synology High Availability V

Log Center

 Syslog Events per Second 800

Virtualization

 VMware vSphere with VAAI V
  Windows Server 2016 V
  Windows Server 2019 V
  Citrix Ready V
  OpenStack V

General Specifications

 Networking Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
  Supported Browsers
  • Google Chrome
  • Firefox
  • Microsoft Edge
  • Internet Explorer 11 onwards
  • Safari 13 onwards
  • Safari (iOS 13.0 onwards)
  • Google Chrome (Android 11.0 onwards)
  Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文

Add-on Packages view the complete package list

Antivirus by McAfee (Trial)

 V

Central Management System

 V

Synology Chat

 Maximum Users 1,500
  Notes
  • The number of concurrent HTTP connections for Synology Chat was configured to the maximum.
  • For tested models with expandable memory, the maximum amount of RAM was installed.

Document Viewer

 V

Download Station

 Maximum Concurrent Download Tasks 80

exFAT Access (Optional)

 V

iSCSI Manager

 Maximum iSCSI Target Number 128
  Maximum iSCSI LUN 256
  iSCSI LUN Clone/Snapshot, Windows ODX

Synology MailPlus / MailPlus Server

 Free Email Accounts 5 (Licenses required for additional accounts)
  Maximum Number of Concurrent Users 150
  Maximum Server Performance 1,484,000 emails per day, approx. 45GB
  Notes
  • Models with more than 4 bays were installed with two SSDs for SSD cache.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • The performance of the mail system will slightly decrease in high-availability mode due to data synchronization between the two servers.
  • Functions that were enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist, content scan, full-text search (English only).

Media Server

 DLNA Compliance V

Moments

 Facial Recognition V
  Subject Recognition V
  Auto Color & Rotate V
  Moments Select V

Snapshot Replication

 Maximum Snapshots per Shared Folder 1,024
  Maximum of System Snapshots 65,536

Surveillance Station

 Maximum IP cam (Licenses required) 40 (including 2 Free License) (See All Supported IP Cameras)
  Total FPS (H.264) 1200 FPS @ 720p (1280x720)
1050 FPS @ 1080p (1920x1080)
600 FPS @ 3M (2048x1536)
440 FPS @ 5M (2591x1944)
320 FPS @ 4K (3840x2160)
  Total FPS (H.265) 1200 FPS @ 720p (1280x720)
1200 FPS @ 1080p (1920x1080)
1120 FPS @ 3M (2048x1536)
600 FPS @ 5M (2591x1944)
480 FPS @ 4K (3840x2160)
  Notes
  • Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
  • The maximum channel number also includes devices installed on Virtual DSM.
  • Total FPS may be affected by other services running at the same time (e.g., archive tasks performed by Archive Vault).

Synology Drive

 Recommended Number of Hosted Files 1,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
  Recommended Number of Concurrent Sync Clients 550 (the number of connections that can be maintained when the recommended number of hosted files was reached)
  Notes
  • Exceeding the recommended numbers above will not block application operations, but may result in longer response time.
  • Utilizing SSD cache can significantly improve performance.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.

Synology Office

 Maximum Users 1,800
  Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM

Video Station

 V

Virtual Machine Manager

 Recommended Virtual Machine Instances 8 (Learn more)
  Recommended Virtual DSM Number (Licenses required) 8 (including 1 Free License)
  Notes The specifications vary depending on system configuration and memory size.

VPN Server

 Maximum Connections 30
