40-bay Synology NAS server for Large Scale Business(16 bays on base, expandable to 40 with 2x RX1217/RX1217RP), Rackmount RS4021xs+

Продуктов код: 55717
NAS устройство Synology
ВНОС ПО ЗАЯВКА
NAS устройство Synology RS4021XS+ NAS устройство Synology RS4021XS+ NAS устройство Synology RS4021XS+ NAS устройство Synology RS4021XS+ NAS устройство Synology RS4021XS+
NAS устройство Synology
Все още няма оценка за продукта.
Напиши ревю | Задай въпрос
Производител:
Synology
Модел:
-
Партиден номер:
RS4021XS+
Гаранция:
60 месеца
Цена с включен ДДС:
11266.80 лв.
/
5760.62 €
Гаранционен срок 60 месеца

Гаранционните условия са определени от производителя

Възможност за лизинг

Кандидатствай бързо и лесно онлайн

Безплатна доставка

До всяко населено място в страната в рамките на 1-3 работни дни

Внос по заявка

Стандартният срок за внос по заявка е 15-90 дни след 50% авансово плащане.

ДОБАВИ В КОЛИЧКАТА
Вземете на лизинг с UniCredit Consumer Financing
Купи на лизинг
По 1 098.51 лв. за 12 мес. Лизингови схеми
Лизингови схеми
Кандидатствайте за лизинг онлайн

1 Добавете желаните продукти в количката си и преминете към страницата за изпращане на поръчката;

2 За начин на плащане изберете "На лизинг с..." и предпочитания от вас лизингодател;

3 Попълнете своите данни и изберете желания срок за лизинг във формата за кандидатстване;

4 Изпратете поръчката си, след което очаквайте одобрение от лизингодателя по телефон или имейл;

Срок UniCredit Consumer Financing TBI Pay
33945.63 лв.
ГПР: 34.52		3924.6 лв.
ГПР: 23.6
62046.05 лв.
ГПР: 34.49		2046.8 лв.
ГПР: 30
91413.98 лв.
ГПР: 34.54
121098.51 лв.
ГПР: 34.53		1107.9 лв.
ГПР: 33.76
15910.36 лв.
ГПР: 34.52
18785.3 лв.
ГПР: 34.51		794.94 лв.
ГПР: 34.66
21696.29 лв.
ГПР: 34.53
24629.81 лв.
ГПР: 34.52		638.45 лв.
ГПР: 34.72
27579.11 лв.
ГПР: 34.49
30538.55 лв.
ГПР: 34.55		544.56 лв.
ГПР: 34.47
33505.88 лв.
ГПР: 34.53
36478.84 лв.
ГПР: 34.49		481.97 лв.
ГПР: 34.08
  • Описание
  • Ревюта
  • Въпроси и отговори

Synology RS4021XS+

  • Параметри: 40-bay Synology NAS server for Large Scale Business(16 bays on base, expandable to 40 with 2x RX1217/RX1217RP), Rackmount RS4021xs+
  • Други:  Intel Xeon D-1541 8-core CPU, 16 GB DDR4 ECC RAM(up to 64GB), 4x Gb + 2x 10Gb LAN(opt. 4x10Gb), RAID 0,1,5,6,10, hotswap HDD, redundand PSU, SSD cache, Btrfs, File/Mail/FTP/Print/DHCP/Directory/VPN/Syslog server,web station, Android/Windows phone app.,sur



Технически данни

CPU

 CPU Model Intel Xeon D-1541
  CPU Architecture 64-bit
  CPU Frequency 8-core 2.1 (base) / 2.7 (turbo) GHz
  Hardware Encryption Engine (AES-NI) V

Memory

 System Memory 16 GB DDR4 ECC UDIMM
  Memory Module Pre-installed 16 GB (16 GB x 1)
  Total Memory Slots 4
  Maximum Memory Capacity 64 GB (16 GB x 4)
  Notes
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • For more information on the recommended memory configurations, visit here.
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage

 Drive Bays 16
  Maximum Drive Bays with Expansion Unit 40 (RX1217/RX1217RP x 2)
  Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA SSD
  Maximum Single Volume Size*
  • 200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
  • 108 TB
  Hot Swappable Drive V
  Notes
  • Storage Pool and volume creation require all drives to be listed as compatible on the device model's compatibility list.
  • "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • Each internal volume (may consist of multiple drives) is expandable up to 108 TB (with memory less than 32 GB) or 200 TB (with memory equal to or greater than 32 GB).

External Ports

 RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)
  RJ-45 10GbE LAN Port 2 (with Link Aggregation / Failover support)
  USB 3.2 Gen 1 Port* 2
  Expansion Port 2
  Notes The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

PCIe

 PCIe Expansion 2 x Gen3 x8 slots (x8 link)

File System

 Internal Drives
  • Btrfs
  • EXT4
  External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
  Notes exFAT Access is purchased separately in Package Center.

Appearance

 Form Factor (RU) 3U
  Size (Height x Width x Depth) 132.3 mm x 482 mm x 656.5 mm
  Weight 17.4 kg
  Rack Installation Support* 4-post 19" rack (Synology Rail Kit - RKS1317)
  Notes The rail kit is sold separately

Others

 System Fan 80 mm x 80 mm x 3 pcs
  Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
  Easy Replacement System Fan V
  Power Recovery V
  Noise Level* 44.7 dB(A)
  Scheduled Power On / Off V
  Wake on LAN / WAN V
  Power Supply Unit / Adapter 800 W
  Redundant Power Supply V
  AC Input Power Voltage 100 V to 240 V AC
  Power Frequency 50/60 Hz, Single Phase
  Power Consumption* 145.79 W (Access)
62.68 W (HDD Hibernation)
  British Thermal Unit 497.14 BTU/hr (Access)
213.74 BTU/hr (HDD Hibernation)
  Notes
  • Power consumption is measured when it is fully loaded with Synology 8TB HAT5300-8T hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

 Operating Temperature 0°C to 35°C (32°F to 95°F)
  Storage Temperature -20°C to 60°C (-5°F to 140°F)
  Relative Humidity 5% to 95% RH

Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • EAC
  • CCC
  • KC
  • UL

Warranty

 5 Years
  Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

 RoHS Compliant

Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 2
  • Quick Installation Guide X 1

Optional Accessories
  Notes All memory modules will operate at the maximum frequency specified by the CPU manufacturer.

DSM Specifications

Storage Management

 Maximum Internal Volume Number 256
  SSD Read / Write Cache (White Paper) V
  SSD TRIM V
  RAID Group V
  Supported RAID Type
  • RAID F1
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
  RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5
  • RAID 1 to RAID 5
  • RAID 5 to RAID 6
  Volume Expansion with Larger HDDs
  • RAID F1
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
  Volume Expansion by Adding a HDD
  • RAID F1
  • JBOD
  • RAID 5
  • RAID 6
  Global Hot Spare Supported RAID Type
  • RAID F1
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10

File Services

 File Protocol CIFS/AFP/NFS/FTP/WebDAV
  Maximum Concurrent CIFS/AFP/FTP Connections 4,000
  Maximum Concurrent CIFS/AFP/FTP Connections (with RAM expansion) 10,000
  Windows Access Control List (ACL) Integration V
  NFS Kerberos Authentication V
  Notes
  • Regarding data concerning tests with RAM expansion, all memory slots are installed with the maximum capacity of supported RAM.
  • During testing, the maximum number of SSDs supported by this model is installed in a RAID 5 configuration.
  • The testing standard was based on the maximum number of concurrent connections supported by this model. During the testing, 25% of the connections were used to transfer files concurrently. The transfer process guaranteed that the connections were not interrupted; the minimum transfer speed was not guaranteed.

Account & Shared Folder

 Maximum Local User Accounts 16,000
  Maximum Local Groups 512
  Maximum Shared Folder 512
  Maximum Shared Folder Sync Tasks 32

High Availability

 Synology High Availability V

Log Center

 Syslog Events per Second 3,000

Virtualization

 VMware vSphere with VAAI V
  Windows Server 2016 V
  Windows Server 2019 V
  Citrix Ready V
  OpenStack V

General Specifications

 Networking Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
  Supported Browsers
  • Google Chrome
  • Firefox
  • Microsoft Edge
  • Internet Explorer 10 onwards
  • Safari 10 onwards
  • Safari (iOS 10 onwards)
  • Google Chrome (Android 6.0 onwards)
  Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文

Add-on Packages view the complete package list

Antivirus by McAfee (Trial)

 V

Central Management System

 V

Synology Chat

 Maximum Users 6,000
  Notes
  • The number of concurrent HTTP connections for Synology Chat was configured to the maximum.
  • For tested models with expandable memory, the maximum amount of RAM was installed.

Document Viewer

 V

Download Station

 Maximum Concurrent Download Tasks 80

exFAT Access (Optional)

 V

iSCSI Manager

 Maximum iSCSI Target Number 256
  Maximum iSCSI LUN 512
  iSCSI LUN Clone/Snapshot, Windows ODX V

Synology MailPlus / MailPlus Server

 Free Email Accounts 5 (Licenses required for additional accounts)
  Maximum Number of Concurrent Users 1,100
  Maximum Server Performance 4,312,000 emails per day, approx. 131GB
  Notes
  • Models with more than 4 bays were installed with two SSDs for SSD cache.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • The performance of the mail system will slightly decrease in high-availability mode due to data synchronization between the two servers.
  • Functions that were enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist, content scan, full-text search (English only).

Media Server

 DLNA Compliance V

Moments

 Facial Recognition V
  Subject Recognition V
  Auto Color & Rotate V
  Moments Select V

Snapshot Replication

 Maximum Snapshots per Shared Folder 1,024
  Maximum of System Snapshots 65,536

Surveillance Station

 Maximum IP cam (Licenses required) 90 (including 2 Free License) (See All Supported IP Cameras)
  Total FPS (H.264) 2700 FPS @ 720p (1280x720)
2250 FPS @ 1080p (1920x1080)
1500 FPS @ 3M (2048x1536)
900 FPS @ 5M (2591x1944)
550 FPS @ 4K (3840x2160)
  Total FPS (H.265) 2700 FPS @ 720p (1280x720)
2700 FPS @ 1080p (1920x1080)
2250 FPS @ 3M (2048x1536)
1500 FPS @ 5M (2591x1944)
1080 FPS @ 4K (3840x2160)
  Notes
  • Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
  • The maximum channel number also includes devices installed on Virtual DSM.
  • Total FPS may be affected by other services running at the same time (e.g., archive tasks performed by Archive Vault).

Synology Drive

 Recommended Number of Hosted Files 5,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
  Recommended Number of Concurrent Sync Clients 2,000 (the number of connections that can be maintained when the recommended number of hosted files was reached)
  Notes
  • Exceeding the recommended numbers above will not block application operations, but may result in longer response time.
  • Utilizing SSD cache can significantly improve performance.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.

Synology Office

 Maximum Users 3,000
  Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM

Video Station

 V

Virtual Machine Manager

 Recommended Virtual Machine Instances 16 (Learn more)
  Recommended Virtual DSM Number (Licenses required) 16 (including 1 Free License)
  Notes The specifications vary depending on system configuration and memory size.

VPN Server

 Maximum Connections 40
