VisualStation VS360HD is a companion system for Surveillance Station. Upgradeable for free1, VS360HD serves as an amazingly compact monitoring and playback station for your local teams — without needing a dedicated computer. In addition, its industrial grade design makes VS360HD ideal for deployments in harsh environments and where space is limited.
Thanks to the versatile features of Surveillance Station, VS360HD is very easy to operate, for both beginner and advanced users. The intuitive interface ensures easy access to most Surveillance Station features2. When you turn on VS360HD, you are taken directly to the Live View panel, so you can perform PTZ actions, switch to Timeline to watch recorded events, or take snapshots and export them to an external storage device, all by using a USB mouse.
Using the latest upgrade3, VS360HD can directly manage and pair video streams to send from multiple Surveillance Stations (via CMS). Just like accessing Surveillance Station via a web browser, VS360HD's brand new multi-tasking interface enables you to efficiently use and manage your surveillance playback and live views. VS360HD supports 720p at up to 36-channel live feeds in H.264, or even reaches a resolution of 5 megapixels at up to 6 channels. VS360HD is also compatible with MJPEG or MPEG4 video formats. Learn more
TV walls are ideal for monitoring a massive amount of cameras at a glance. Thanks to the dual video output, you can connect multiple VS360HD units to a KVM switch to create a cost-efficient, easy to setup, and scalable TV wall.
Despite its small form factor, VS360HD packs a multitude of ports for guaranteed flexibility. With the USB 3.0 and 2.0 ports, it's easy to connect a drive and save video recordings or snapshots. With a total of three USB ports, the VS360HD can be connected to a mouse, keyboard, and even a joystick4 for PTZ control.
Free from mechanical moving parts, VS360HD is more resistant against vibration and hardware failure. Its solid outer case and optimized design allow VS360HD to run within industrial temperature ranges, from -20˚C to 50˚C. In addition, VS360HD is EN45545 and EN50155 certified.
Thanks to its fanless design, VS360HD is completely silent, and its energy consumption is less than 5W at peak operation, even less than a smartphone charger. Even more impressive is that the whole system fits in a palm-sized enclosure and can be easily attached to a wall or the back of a screen with a VESA compatible mount.
Notes:
___
Hardware Specifications | |
Video Outputs | |
Video Output | VGA X 1, HDMI X 1 |
Supported Video Resolution | 1080p 60Hz |
Audio Input | 3.5 mm Stereo Audio Jack x 1 |
Audio Output | 3.5 mm Stereo Audio Jack x 1 |
USB 2.0 Port | 2 |
USB 3.0 Port | 1 |
Appearance | |
Size | 32 mm x 130 mm x 130 mm |
Weight | 0.3 kg |
Others | |
RJ-45 1GbE LAN Port | 1 |
Power Supply Unit / Adapter | 36W |
AC Input Power Voltage | 100V to 240V AC |
Power Frequency | 50/60 Hz, Single Phase |
Power Consumption* | 4.76W (36ch full-load) 3.61W (Power on Idle) |
Environment | |
Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
Adapter Operating Temperature | 0°C to 40°C (32°F to 104°F) |
Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
Relative Humidity | 5% to 95% RH |
Certification |
|
Warranty | 3 Years |
Software Specifications | |
Maximum IP cam | 36 |
Total FPS (H.264)* | 360 FPS @ 720p (1280x720), 36 Channels 160 FPS @ 1080p (1920×1080), 16 Channels 90 FPS @ 3M (2048x1536), 9 Channels 60 FPS @ 5M (2591x1944), 6 Channels |
Total FPS (MJPEG)* | 150 FPS @ 720p (1280x720), 15 Channels 40 FPS @ 1080p (1920×1080), 4 Channels 20 FPS @ 3M (2048x1536), 2 Channels 10 FPS @ 5M (2591x1944), 1 Channel |
Video Compression Format |
|
Audio Codec |
|
Live View / Recording Playback | Yes |
Snapshot Support | Yes |
eMap Support | Yes |
PTZ Control / Patrol | Yes |
Log Viewer | Yes |
Notes |
|
Environment & Packaging | |
Environment | RoHS Compliant |
Packaging Content |
|
