Higher Transmission Capacity & More Stable Connections
MIMO Technology means the TL-PA8010P KIT can use the 3 wires, including the live, neutral and earth to create multiple data paths, meaning that you benefit from faster data throughput and more stable connections.
Gigabit Port for Ultra-fast Datasheet Transfer
With one Gigabit Ethernet port, TL-PA8010P KIT allows users to connect a bandwidth intensive device to the Internet at high speeds and ensures the smooth transmission of Ultra HD video streaming. This makes the TL-PA8010P KIT the perfect home entertainment companion.
Plug and Play,
No Configuration Required
Connect a powerline adapter to the router; plug another powerline adapter into a wall socket in another room, and connect it to your Internet enabled device via Ethernet - and you’re done!
Extra Power Socket for Additional Devices
The integrated power socket, with power output of up to 16A*, means the powerline can be used like a traditional electrical socket. Simply plug in your device or extension lead as though it were a normal wall socket. The built-in noise filter also helps to prevent electrical signal noise from affecting Powerline performance.
*Power output of up to 16A is suitable for high-power electrical appliances to be connected.
Power Save by Up to 85%
TL-PA8010P is a new-generation of Powerline adapter. Its sophisticated Power-Saving mode automatically switches from its regular “Working” mode to “Power-Saving” mode reducing energy consumption by up to 85%.
The theoretical maximum channel data transfer rate is derived from HomePlug AV2 specifications. Actual data transfer rate will vary from network environment including: distance, network traffic, noise on electrical wires, building material and construction, quality of electrical installation and other adverse conditions.
Actual data will vary because of the network conditions and environment factors.
| HARDWARE FEATURES |
| Plug Type |
EU, UK |
| Standards and Protocols |
HomePlug AV2, HomePlug AV, IEEE1901, IEEE802.3, IEEE802.3u, IEEE802.3ab |
| Interface |
1 * Gigabit Ethernet Port, Power Socket |
| Button |
Pair Button |
| Power Consumption |
Maximum: 6W (220V/50Hz) Typical: 6W (220V/50Hz) Standby: 0.5W (220V/50Hz) |
| LED Indicator |
PWR, PLC, ETH |
| Dimensions ( W x D x H ) |
5.2×2.8×1.7 in. (131×72×42 mm) |
| Range |
300 Meters over electrical circuit |
| Power Output to Integrated Socket |
16 A |
| SOFTWARE FEATURES |
| Modulation Technology |
OFDM (PLC) |
| Encryption |
Powerline Security: 128-bit AES |
| OTHERS |
| Certification |
CE, RoHS |
| Package Contents |
Powerline Ethernet Adapter 6.5 ft. (2 m) Ethernet cable (RJ45) Resource CD Quick Installation Guide |
| System Requirements |
Windows 2000/XP/2003/Vista, Windows 7/8, Mac, Linux |
| Environment |
Operating Temperature: 0°C~40°C (32°F ~104°F) Storage Temperature: -40°C~70°C (-40°F ~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
