TP-Link TL-EAP110, 300Mbps Wireless N Ceiling Mount Access Point

Продуктов код: 12050
Точки за достъп (access point) TP-Link
TP-Link TL-EAP110, 300Mbps Wireless N Ceiling Mount Access Point (умалена снимка 1) TP-Link TL-EAP110, 300Mbps Wireless N Ceiling Mount Access Point (умалена снимка 2) TP-Link TL-EAP110, 300Mbps Wireless N Ceiling Mount Access Point (умалена снимка 3) TP-Link TL-EAP110, 300Mbps Wireless N Ceiling Mount Access Point (умалена снимка 4) TP-Link TL-EAP110, 300Mbps Wireless N Ceiling Mount Access Point (умалена снимка 5) TP-Link TL-EAP110, 300Mbps Wireless N Ceiling Mount Access Point (умалена снимка 6) TP-Link TL-EAP110, 300Mbps Wireless N Ceiling Mount Access Point (умалена снимка 7) TP-Link TL-EAP110, 300Mbps Wireless N Ceiling Mount Access Point (умалена снимка 8)
Точки за достъп (access point) TP-Link
Все още няма оценка за продукта.
Напиши ревю | Задай въпрос
Производител:
TP-Link
Модел:
TL-EAP110
Партиден номер:
-
Цена с включен ДДС:
65.87 лв.

Безплатна доставка за поръчки над 99.99лв. с ДДС

До всяко населено място в страната в рамките на 1-3 работни дни

ДОБАВИ В КОЛИЧКАТА

Можете да поръчате и по телефона:
(+359 2) 965 89 89

  • Информация за TP-Link TL-EAP110

  • Видео (1)
  • Ревюта
  • Въпроси и отговори

300Mbps Wireless N Ceiling Mount Access Point
EAP110
EAP Controller Software enables administrators to easily manage hundreds of EAPs
Supports passive PoE for convenient installation up to 100meters
Ceiling mounting design with chassis make it easy to deploy on a wall or ceiling
Captive portal provides one convenient method of authentication for Wi-Fi guests
Multi-SSID divides multiple wireless networks for different users
Enterprise class Wi-Fi security help to decrease network security threats



Flexible Placement
Easy mounting design & PoE
The EAP’s “ceiling lamp” appearance and easy mounting design with chassis make it easy to be integrated seamlessly into any wall or ceiling surface to blend in with most interior decorations. EAP110 support Passive PoE to make deployment effortless and flexible.



Business Class Wireless
Powerful Hardware
EAP110 features 802.11n Wi-Fi and 2*2 MIMO technology, wireless speeds of up to 300Mbps
With Qualcomm Atheros 560MHz chipsets, EAP ensures incredible wireless coverage and reliability



Free Centralized Management Platform
EAP Controller Software

EAP Controller Software enables users to manage hundreds of TP-LINK’s EAPs simultaneously and easily from PCs in the network, making centralized business Wi-Fi management efficient, visible and more cost-effective like never before.



Efficient Guest Authentication Captive Portal
Captive portal provides one convenient method of authentication for Wi-Fi guests. A captive portal requires users to perform certain actions before network access is allowed. The required action must be verified by an external portal server or customized database by the administrator, which can be simply viewing and agreeing to an acceptable use policy, or entering a user ID and password.



Applicable to Multi-user Environment
Designed for Business Performance

With easy mounting design, PoE power supply, Cluster feature, Centralized management software, Captive portal, Auto RF management, and business hardware, EAP series are specially designed for the high-density, most demanding business environments, including schools, hotels, and enterprises.



EAP SeriesEAP110EAP120EAP220
Product 300Mbps Wireless N
Access Point
300Mbps Wireless N
Gigabit Access Point
N600 Wireless
Dual Band Gigabit Access Point
Wireless Standards IEEE 802.11 n/b/g IEEE 802.11 n/b/g IEEE 802.11 n/b/g/a
Speed 2.4GHz : 300Mbps 2.4GHz : 300Mbps 2.4GHz : 300Mbps
5GHz : 300Mbps
Ethernet Port 10/100Mbps Port*1 Gigabit Port*1 Gigabit Port*1
PoE Passive PoE 802.3af 802.3af
Internal Antennas 2 * 3dBi 2 * 4dBi 4 * 4dBi
EAP Controller
Multiple SSIDs 8 8 16
Captive Portal
MAC Filtering
Wireless Schedule
Rogue AP Detection
Automatic RF Management

Note:
For EAP120 that’s currently supporting cluster function, please upgrade the device’s firmware to the latest to be compatible with the EAP controller software.



HARDWARE FEATURES
Interfaces Fast Ethernet (RJ-45) Port *1(Support Passive PoE)
Button Reset
Power Supply 24VDC / 1A Passive PoE Supply
Power Consumption 7.7W
Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H ) 7.1 x 7.1 x 1.9 in. (180*180*47.5mm)
Antenna Type Internal 2* 3dBi Omni
Mounting Ceiling /Wall Mounting (Kits included)
Physical Security Lock Kensington Lock Slot
Watch Dog Yes
WIRELESS FEATURES
Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency 2.4-2.4835GHz
Signal Rate 11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity 300M: -71dBm@10% PER
150M: -75dBm@10% PER
54M: -78dBm@10% PER
11M: -93dBm@8% PER
6M: -92dBm@10% PER
1M: -96dBm@8% PER
Wireless Functions Multiple SSIDs (Up to 8 SSIDs)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless Security Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK
Transmission Power CE:
<20dBm
FCC:
<26dBm
MANAGEMENT
EAP Controller Software Yes
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1,v2c
System Logging Local/Remote Syslog Local/Remote Syslog
Telnet Yes
Web-based Management HTTP/HTTPS
OTHERS
Certification CE, FCC, RoHS
Package Contents 300Mbps Wireless N Ceiling Mount Access Point EAP110
Passive PoE Adapter,
Power Cord,
Mounting Kits,
Resource CD
Installation Guide
System Requirements Microsoft Windows 8/7/Vista/XP
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
