Thermal extended burn-in test.
Each drive is put through extended burn-in testing with thermal cycling to ensure reliable operation.
Dynamic fly height technology.
Each read-write head’s fly height is adjusted in real time for optimum reliability.
Ideal for:
The Se is best suited for bulk cloud storage, replicated environments, content delivery networks (CDNs), SMB network attached storage (NAS), backup and archiving.
Product Specifications |
 |
 |
Interface |
SATA 6 Gb/s |
 |
Performance Specifications |
 |
 |
Rotational Speed |
7,200 RPM (nominal) |
 |
Buffer Size |
64 MB |
 |
Load/unload Cycles |
600,000 minimum |
 |
Transfer Rates |
 |
Buffer To Host (Serial ATA) |
6 Gb/s (Max) |
 |
Physical Specifications |
 |
 |
Capacity |
2 TB |
 |
User Sectors Per Drive |
3,907,029,168 |
 |
Performance Specifications |
 |
Target Performance |
 |
MTBF |
800,000 hours |
 |
Physical Dimensions |
 |
English |
 |
Height |
1.028 Inches |
 |
Depth |
5.787 Inches |
 |
Width |
4.00 Inches |
 |
Weight |
1.66 Pounds |
 |
Metric |
 |
Height |
26.1 mm |
 |
Depth |
147 mm |
 |
Width |
101.6 mm |
 |
Weight |
0.75 kg |
 |
Power Management |
 |
 |
Read (Peak Watts) |
9.50 Watts |
 |
Write (Peak Watts) |
9.10 Watts |
 |
Environmental Specifications |
 |
Shock |
 |
Operating Shock (Read) |
65G, 2 ms |
 |
Non-operating Shock |
300G, 2 ms |
 |
Acoustics |
 |
Idle Mode |
31 dBA (average) |
 |
Seek Mode 0 |
34 dBA (average) |
 |
Temperature (English) |
 |
Operating |
41° F to 131° F |
 |
Non-operating |
-40° F to 158° F |
 |
Temperature (Metric) |
 |
Operating |
5° C to 55° C |
 |
Non-operating |
-40° C to 70° C |
 |
Electrical Specifications |
 |
Current Requirements |
 |
Power Dissipation |
 |
Read/Write |
9.50 Watts |
 |
Idle |
8.10 Watts |
 |
Compatibility |
 |
Operating System |
 |
Compatibility |
Windows/Mac |
 |
As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576 bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, megabit per second (Mb/s) = one million bits per second, and gigabit per second (Gb/s) = one billion bits per second. |
|
