D-Link DES-108, 8-Port Fast Ethernet Unmanaged Desktop Switch

Name: D-Link DES-108, 8-Port Fast Ethernet Unmanaged Desktop Switch
Brand: D-Link
SKU: DES-108
Price: 45.96 BGN
Availability: OnlineOnly

Продуктов код: 9579

Все още няма оценка за продукта.
Напиши ревю | Задай въпрос

Производител:

D-Link

Модел:

DES-108

Партиден номер:

DES-108

Гаранция:

60 месеца

Брой портове:

Жична мрежа (LAN)- макс. скорост на обмен:

Megabit (Fast) Ethernet (10/100)

Цена с включен ДДС:

45.96 лв.

Гаранционен срок 60 месеца

Гаранционните условия са определени от производителя

Безплатна доставка за поръчки над 99.99лв. с ДДС

До всяко населено място в страната в рамките на 1-3 работни дни

ДОБАВИ В КОЛИЧКАТА

D-Link DES-108

Datasheet

The DES-108 8-Port Fast Ethernet Unmanaged Desktop Switch is a 8-port 10/100 Mbps Fast Ethernet switch that allows you to quickly set up a wired network. Connect the DES-108 to multiple computers together to share files and folders, or connect it to a router to share an Internet connection.

Auto-Sensing 10/100 Ports

The DES-108 uses auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to Ethernet and Fast Ethernet devices to create an integrated network. These ports detect the network speed and auto-negotiate between 10BASE-T and 100BASE-TX, as well as between full and half-duplex, allowing you to get the maximum speed possible for each device connected to your network.

Auto MDI/MDIX Crossover

All of the ports on the DES-108 support automatic MDI/MDIX crossover, eliminating the need for crossover cables or uplink ports. Each port can be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables. In addition, the DES-108 features multiple front, easy-to-access Ethernet ports with two colour LED indicators per port to easily distinguish link status.

Flow Control for Secure Transmission

When a port reaches its receiving buffer capacity, the 802.3x flow control feature activates to minimize dropped packets. By minimizing the number of dropped packets, the switch provides a more reliable connection for all of your connected devices while surfing the web, playing games, or accessing media.

Think Green

The DES-108 is a plug-and-play networking switch that offers D-Link’s Green Technology to save energy and reduce heat, which in turn extends product life without sacrificing performance or functionality. The switch supports IEEE 802.3az Energy-Efficient Ethernet (EEE) which detects when a connected computer is shut down or when there is no Ethernet traffic, in which the switch will proceed to power down the idle port, saving a substantial amount of power.

Key Features

Inexpensive Fast Ethernet solution for Home/SOHO
Eight 10/100 Mbps Fast Ethernet ports
Auto MDI/MDIX crossover for all ports
Store-and-forward switching scheme
Full/half-duplex for Ethernet/Fast Ethernet speeds
IEEE 802.3x Flow Control
Jumbo Frames:
- 1536 Bytes
Supports 802.1p QoS
- 2 Queues, WRR Mode
RoHS compliant
Plug-and-play installation

Switching Fabric

1.6 Gbps

Standards

IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x flow control
IEEE 802.3az Energy-Efficient Ethernet (EEE)

Protocol

CSMA/CD

Data Transfer Rates

Ethernet:
- 10 Mbps (half duplex)
- 20 Mbps (full duplex)
Fast Ethernet:
- 100 Mbps (half duplex)
- 200 Mbps (full duplex)

Topology

Star

Media Interface Exchange

Auto MDI/MDIX adjustment for all ports

Network Cables

10BASE-T:
- UTP CAT 3/4/5/5e (100 m max.)
- EIA/TIA-586 100-ohm STP (100 m max.)
100BASE-TX:
- UTP CAT 5/5e (100 m max.)
- EIA/TIA-568 100-ohm STP (100 m max.)

LED Indicators
