Software Specification
|
|
|
Standards and Protocols
|
IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3ad, 802.3x, 802.1d, 802.1s, 802.1w, 802.1q, 802.1p, 802.1x, SNMP
|
|
Basic Function
|
MAC Address Auto-Learning and Auto-aging
|
|
Storm Control (Broadcast, Multicast, Unknown unicast)
|
|
|
Port Mirroring
|
|
|
IGMP Snooping
|
|
|
MAC Address Table
|
8k
|
|
Switching Capacity
|
12.8Gbps
|
|
Transmission Method
|
Store-and-Forward
|
|
Priority
|
Port-based Priority
|
|
IEEE 802.1p based Priority: 4 Queues
|
|
|
IP DSCP based Priority
|
|
|
Link Aggregation
|
IEEE 802.3ad LACP Link Aggregation
|
|
Spanning Tree
|
IEEE 802.1d Spanning Tree
|
|
IEEE 802.1s Multiple Spanning Tree
|
|
|
IEEE 802.1w Rapid Spanning Tree
|
|
|
BPDU Filtering
|
|
|
VLAN
|
Port Based VLAN
|
|
802.1Q Tag-VLAN
|
|
|
GARP/GVRP
|
|
|
Management Access Control
|
Based on Port
|
|
Based on MAC
|
|
|
Based on IP
|
|
|
Based on VLAN
|
|
|
Based on LAG
|
|
|
Security & Authentication
|
Port Security
|
|
Static MAC Address Binding
|
|
|
802.1x port-based Access Control
|
|
|
RADIUS
|
|
|
TACACS+
|
|
|
Network Management
|
Telnet, CLI/Console, SSH v1/v2
|
|
Web (Http/Https), SSL
|
|
|
SNMP v1/v2c/v3
|
|
|
SNMP MIB-II, Ethernet-like MIB and Bridge MIB
|
|
|
RMON statistics, history, alarm and event group
|
|
|
System Function
|
Fixed IP Address Setting
|
|
VCT (visual cable test )
|
|
|
System Log
|
|
|
Port Flow Statistics
|
|
|
TFTP Upgrade
|
|
|
Hardware Specification
|
||
|
Ports
|
24 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
|
|
|
2 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
|
||
|
2 Gigabit SFP ports
|
||
|
1 RS232 Console port
|
||
|
Network Media
|
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX/1000Base-T: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-X: MMF, SMF |
|
|
LED Indicators
|
Link/Act
|
10Mbps, 1000Mbps, SFP
|
|
Else
|
Power, System,
|
|
|
Safety & Emission
|
FCC, CE
|
|
|
Dimensions (W*D*H)
|
17.3*7.1*1.7 in. (440*180*44 mm)
|
|
|
Environment
|
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
|
|
Power
|
100-240VAC, 50/60Hz
|
|
